Certa’s Aluminium Trefoil Cable Cleats are engineered to securely support and retain three single-core power cables arranged in a trefoil formation. Manufactured from high-strength LM6 Aluminium Alloy, these cable cleats provide exceptional mechanical stability, corrosion resistance, and reliable cable restraint during normal operating conditions as well as short-circuit events.
Designed for Low Voltage (LV), Medium Voltage (MV), and High Voltage (HV) cable installations, the Aluminium Trefoil Cable Cleat features a two-piece, double-bolt fixing design with protective rubber liners to prevent cable damage while ensuring a firm and secure grip. Epoxy-coated for enhanced durability and manufactured in accordance with IEC 61914, these cable cleats are ideal for industrial, utility, renewable energy, and infrastructure applications.
The Aluminium Trefoil Cable Cleat is specifically designed to securely clamp three single-core cables in a trefoil arrangement, reducing cable movement during normal operation and electrical fault conditions.
Manufactured using LM6 Aluminium Alloy, these cable cleats provide outstanding structural integrity while maintaining a lightweight design suitable for demanding installations.
The epoxy-coated aluminium construction offers superior protection against corrosion, moisture, chemicals, and harsh outdoor environments.
Integrated rubber liners cushion the cable surface, reducing vibration and preventing damage to cable insulation during long-term operation.
Recommended for applications above 1 kVA, these cable cleats deliver dependable cable retention for critical power distribution systems.
| Specification | Details |
|---|---|
| Product Type | Aluminium Trefoil Cable Cleat |
| Material | LM6 Aluminium Alloy |
| Design | Two-Piece Double Bolt Fixing |
| Coating | Epoxy Coated |
| Colour | Silver |
| Cable Diameter Range | 15 mm – 155 mm |
| Suitable Cable Type | LV, MV & HV Power Cables |
| Operating Temperature | -60°C to +90°C |
| Protective Liner | Rubber Liner |
| Available Sizes | 8 Standard Sizes |
| Standard | IEC 61914 |
Certa manufactures premium-quality cable management solutions that combine strength, durability, and safety. The Aluminium Trefoil Cable Cleat is precision-engineered using LM6 Aluminium Alloy to provide secure cable restraint, superior corrosion resistance, and reliable performance in demanding industrial and utility applications. With its double-bolt fixing design, protective rubber liners, and compliance with IEC 61914, it is an ideal solution for modern power distribution systems.
