CW Industrial Brass Cable Glands are high-performance compression cable glands designed for Steel Wire Armoured (SWA) and Aluminium Wire Armoured (AWA) cables in both indoor and outdoor applications. Featuring a robust three-part armour locking system and IP66 ingress protection, CW glands provide secure cable termination, reliable environmental sealing, and excellent mechanical retention for demanding industrial environments.
CW Brass Cable Glands are engineered to provide safe and reliable cable termination for armoured cables used in industrial, commercial, and infrastructure projects. Manufactured from premium-quality brass, these glands offer exceptional durability, corrosion resistance, and long service life even in challenging operating conditions.
Certa CW Industrial Brass Cable Glands are manufactured in accordance with BS6121:2005 and IEC/EN 62444 standards, ensuring compliance with international quality and performance requirements. These glands are suitable for plastic or rubber insulated, plastic or rubber sheathed armoured cables with extruded or lapped bedding, including both single-core and multicore cable configurations.
The compression sealing design combined with a three-part armour locking mechanism ensures effective armour clamping, superior ingress protection, and secure cable retention. CW glands are widely used where both environmental protection and armour continuity are essential for maintaining safe electrical installations.
| Design Standard | BS6121:2005, IEC/EN 62444 |
| Product Type | CW Industrial Brass Cable Gland |
| Material | Brass |
| Finish | Natural Brass / Nickel Plated |
| Size Range | M16 to M90 |
| Ingress Protection | IP66 |
| Operating Temperature | -40°C to +100°C |
| Sealing Type | Compression |
| Armour Clamping | Three-Part Armour Lock |
| Sealing Area | Outer Sheath |
| Cable Type | Armoured Cables (SWA/AWA) |
| Cable Construction | Extruded or Lapped Bedding |
| Application | Indoor & Outdoor |
| Accessories Available | Lock Nut, Shroud, IP Washer |
| PRODUCT CODE | SIZE | CABLE DIMENSIONS | GLAND DIMENSIONS | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Armour wire Diameter | Under Armour Dia(A) mm (Max) | Overall Dia (B) mm (Max) | ISO ENTRY THREAD C mm | E MM | Length from shoulder F mm | Across Flat Dia G mm | Across Flat Dia H mm | ||
| CCW16S | 16S | 0.90 | 8.00 | 11.00 | M16 | 10 | 40.00 | 20.00 | 23.00 |
| CCW16L | 16L | 0.90/1.25 | 9.00 | 13.50 | M16 | 10 | 40.00 | 20.00 | 23.00 |
| CCW20S | 20S | 0.90/1.25 | 12.50 | 15.00 | M20 | 10 | 40.00 | 22.00 | 24.00 |
| CCW20L | 20L | 0.90/1.25 | 14.30 | 19.00 | M20 | 10 | 40.00 | 26.00 | 29.00 |
| CCW25S | 25S | 0.90/1.25 | 18.00 | 23.60 | M25 | 10 | 41.10 | 31.00 | 34.00 |
| CCW25L | 25L | 0.90/1.25 | 19.00 | 25.00 | M25 | 10 | 41.10 | 34.20 | 37.90 |
| CCW32S | 32S | 1.60/2.00 | 26.50 | 31.00 | M32 | 10 | 44.00 | 41.00 | 45.70 |
| CCW32L | 32L | 1.60/2.00 | 27.00 | 32.50 | M32 | 10 | 44.00 | 41.25 | 46.00 |
| CCW40S | 40S | 1.60/2.00 | 31.70 | 37.50 | M40 | 11 | 46.00 | 45.00 | 50.00 |
| CCW40L | 40L | 1.60/2.00 | 33.00 | 39.00 | M40 | 11 | 46.00 | 49.00 | 54.00 |
| CCW50S | 50S | 2.00/2.50 | 39.50 | 46.00 | M50 | 11 | 48.80 | 56.50 | 62.70 |
| CCW50L | 50L | 2.50 | 43.00 | 50.00 | M50 | 11 | 48.80 | 61.00 | 68.00 |
| CCW63S | 63S | 2.50 | 50.50 | 59.00 | M63 | 15 | 53.00 | 72.50 | 81.00 |
| CCW63L | 63L | 2.50 | 56.00 | 62.00 | M63 | 15 | 53.00 | 76.00 | 85.00 |
| CCW75S | 75S | 2.50 | 62.50 | 71.00 | M75 | 15 | 56.00 | 85.00 | 95.00 |
| CCW75L | 75L | 2.50/3.15 | 64.00 | 75.00 | M75 | 15 | 56.80 | 91.00 | 98.10 |
| CCW90L | 90L | 3.15 | 76.00 | 84.00 | M90 | 20 | 48.00 | 103.00 | 114.00 |
Certa CW Industrial Brass Cable Glands are designed to deliver superior sealing performance, secure armour clamping, and long-lasting reliability for armoured cable installations. With IP66 protection, a three-part armour locking system, and compliance with BS6121:2005 and IEC/EN 62444 standards, CW glands provide a trusted solution for indoor and outdoor electrical applications across industrial, commercial, and infrastructure sectors.
